Learning about Kubernetes Networking Policies
Jumpstarting your understanding of Kubernetes Networking Policies.
We are about to get hands-on with Kubernetes and network policies by walking through some common use cases. By the end of this post, you should have a basic understanding of how to implement networking policies in Kubernetes, and how to allow / block traffic within your cluster.
Overview
- Set up the testing environment using Minikube
- Deploy an Nginx container to the
default
namespace - Deploy a container to a new namespace to use as an interactive shell to connect with the Nginx container
- Dive into use cases and policies to showcase how it works
Tools I’m using for this exercise:
- Minikube
- VS Code for editing
- Windows 10 Pro
- cmder terminal
If you are using Mac or Linux, you should still be able to follow along.
Setup
By default, Kubernetes allows all ingress and egress traffic.
- Ensure you have the ability to control a test Kubernetes cluster. I use Minikube so here’s my command to start up a cluster with Calico installed. You can use any networking interface that supports Network Policies.
minikube start --network-plugin=cni --cni=calico
If you have Calico installed, see if it’s running.
kubectl get pods -l k8s-app=calico-node -n kube-system
Deploy an Nginx container
We are going to deploy an Nginx pod to use as the target server for this demo.
apiVersion: apps/v1
kind: Deployment
metadata:
name: nginx-for-calico-demo
namespace: default
spec:
selector:
matchLabels:
app: nginx
replicas: 1
template:
metadata:
labels:
app: nginx
spec:
containers:
- name: nginx
image: nginx:1.20.0
ports:
- containerPort: 80
- Apply the YAML to your cluster.
kubectl apply -f https://raw.githubusercontent.com/airwavetechio/calico-istio-demo/main/deployments/nginx.yaml
2. Let’s create a service.
kubectl expose deployment nginx-for-calico-demo
We now have something to test against.
Deploy a container to a new namespace to use as an interactive shell to connect with the Nginx container
Now that we have an accessible web server in the default
namespace, let’s create a pod with an interactive shell so we can access it from within the cluster.
- Create a new namespace
kubectl create ns airwave-dev
2. Run an interactive shell in the airwave-dev
namespace and once that shell appears, use wget
to access the Nginx pod by its service name.
kubectl run -n airwave-dev -it busybox --image=busybox --rm -- shwget --spider http://nginx.default
If all went well, you should be able to access the nginx-for-calico
service and pod from the busybox
instance in the airwave-dev
namespace. You’ll get a remote file exists
response. Leave this terminal alone and open a new session.
Dive into use cases and policies to showcase how it works
Official Documentation: https://kubernetes.io/docs/concepts/services-networking/network-policies/
1. The first use case is blocking all ingress traffic for the default
namespace.
---
apiVersion: networking.k8s.io/v1
kind: NetworkPolicy
metadata:
name: default-deny-all
spec:
podSelector: {}
policyTypes:
- Ingress
Here is a network policy that denies all ingress traffic. Notice how namespace
is not defined so by default, it will be applied to the context you are in. In my case, it’s the default
namespace.
The YAML is straightforward except for podSelector
. We will get more into that later, but right now, just know that {}
means that the network policy applies to all pods in the namespace it’s being applied to.
In your new terminal session, apply this to your cluster and it will block all ingress traffic to that namespace.
kubectl apply -f https://raw.githubusercontent.com/airwavetechio/calico-istio-demo/main/policies/deny-default-ingress.yaml
Now that the networking policy has been applied, you should not be able to hit the Nginx container from the busybox
pod in the airwave-dev
namespace. Let’s try it again.
Run the busybox
pod if it’s not still open in your terminal and try the wget
command again. It should time out because we blocked all ingress traffic going into default
.
kubectl run -n airwave-dev -it busybox --image=busybox --rm -- shwget --spider http://nginx-for-calico-demo.default
Congrats, you just set up your first networking policy! You have blocked all ingress traffic from going into the default
namespace.
2. For our 2nd use case, let’s block egress traffic for the namespace airwave-dev
.
Notice below in the egress policy namespace
is defined. This is because we want to block all egress traffic coming out of the airwave-dev
namespace, which would include the busybox
pod.
---
apiVersion: networking.k8s.io/v1
kind: NetworkPolicy
metadata:
name: deny-all-egress
namespace: airwave-dev
spec:
podSelector: {}
policyTypes:
- Egress
Again, podSelector: {}
applies to every pod in the airwave-dev
namespace. Apply the egress policy:
kubectl apply -f https://raw.githubusercontent.com/airwavetechio/calico-istio-demo/main/policies/deny-airwave-dev-egress.yaml
In the busybox
interactive terminal session, try any command that relies on outbound network access. In my example, I’m using nslookup
.
nslookup www.google.com
Congrats! You now blocked all egress traffic coming from the airwave-dev
namespace.
3. Our third example will allow traffic to nginx
from our busybox
pod in the airwave-dev namespace, but will still block all the other traffic.
In order to achieve this, we will need to make a few changes.
- Label the namespaces
- Allow DNS lookups using an egress policy to
kube-system
namespace - An ingress policy allowing
nginx
to receive traffic frombusybox
- An egress policy allowing
busybox
to send traffic tonginx
Label the Namespaces
The reason we need to label the namespaces is that the network policies currently don’t allow targeting namespaces by their name. Since they allow targeting namespaces by labels, let’s create a few.
kubectl label namespace airwave-dev ns=airwave-dev
kubectl label namespace kube-system ns=kube-system
kubectl label namespace default ns=default
Allow DNS using an egress policy
The following YAML allows for DNS access from the airwave-dev
namespace to kube-system
. This is necessary because we are accessing the DNS name of the service (nginx-for-calico-demo.default
) and the Kubernetes CoreDNS service lives in the kube-system
namespace. We were accessing everything by IP, this step wouldn’t be necessary.
apiVersion: networking.k8s.io/v1
kind: NetworkPolicy
metadata:
name: allow-dns-access
namespace: airwave-dev
spec:
podSelector: {}
policyTypes:
- Egress
egress:
- to:
- namespaceSelector:
matchLabels:
ns: kube-system
ports:
- protocol: UDP
port: 53
We are introduced to namespaceSelector
and ports
. These are the ways to target your egress destination. In other words, this policy allows traffic from any pod in the airwave-dev
namespace, to any pod within a namespace labeled ns=kube-system
over UDP port 53.
Apply the policy and test nslookup
again.
kubectl apply -f https://raw.githubusercontent.com/airwavetechio/calico-istio-demo/main/policies/allow-dns.yaml
An ingress policy allowing nginx
to receive traffic from busybox
Network policies are unidirectional, meaning if you have to specifically state ingress and egress rules for source and destination traffic.
apiVersion: networking.k8s.io/v1
kind: NetworkPolicy
metadata:
name: allow-ingress-from-busybox
namespace: default
spec:
podSelector:
matchLabels:
app: nginx
policyTypes:
- Ingress
ingress:
- from:
- namespaceSelector:
matchLabels:
ns: airwave-dev
In our example, nginx-for-calico-demo
has a label app=nginx
. The policy above states in the default
namespace, pods with the label app=nginx
are allowed ingress traffic from all pods in the namespaces with the label ns=airwave-dev
.
kubectl get deployment -o wide
to check my labels.As mentioned earlier, we have podSelector
. This allows associating network policies with pods and their labels. The usage of labels here is similar to using labels and selectors with services, and with affinity.
kubectl apply -f https://raw.githubusercontent.com/airwavetechio/calico-istio-demo/main/policies/allow-ingress-from-busybox.yaml
At this point, if you try to access the Nginx server, you will still get a timeout. That’s because we need to create an egress rule for pods in the airwave-dev
namespace.
An egress policy allowing busybox
to send traffic to nginx
apiVersion: networking.k8s.io/v1
kind: NetworkPolicy
metadata:
name: allow-egress-from-busybox
namespace: airwave-dev
spec:
podSelector: {}
policyTypes:
- Egress
egress:
- to:
- namespaceSelector:
matchLabels:
ns: default
podSelector:
matchLabels:
app: nginx
This policy states we are allowing all traffic from the airwave-dev
namespace to a pod with the label app=nginx
, within a namespace labeled ns=default
.
kubectl apply -f https://raw.githubusercontent.com/airwavetechio/calico-istio-demo/main/policies/allow-egress-to-nginx.yaml
Wrapping up
If you’ve made it this far, there’s one more thing to do. Let’s test the network policies.
In your interactive shell:
- Access the
Nginx
web server from thebusybox
instance. According to the diagram above, this should work.
wget http://nginx-for-calico-demo.default --spider
- Access DNS from your
busybox
instance. According to the diagram above, this should work.
nslookup www.google.com
- Access an external website from the
busybox
instance. According to the diagram above, this should NOT work.
wget --spider https://www.google.com
UNINSTALLING
If you’d like to roll back any of the changes, use the following:
kubectl delete -f https://raw.githubusercontent.com/airwavetechio/calico-istio-demo/main/policies/allow-dns.yaml
kubectl delete -f https://raw.githubusercontent.com/airwavetechio/calico-istio-demo/main/policies/allow-ingress-from-busybox.yaml
kubectl delete -f https://raw.githubusercontent.com/airwavetechio/calico-istio-demo/main/policies/allow-egress-to-nginx.yaml
kubectl delete -f https://raw.githubusercontent.com/airwavetechio/calico-istio-demo/main/policies/deny-default-ingress.yaml
kubectl delete -f https://raw.githubusercontent.com/airwavetechio/calico-istio-demo/main/policies/deny-airwave-dev-egress.yaml
kubectl delete ns airwave-dev
kubectl delete deployment nginx-for-calico-demo
That will conclude our lesson for today. I hope you were able to follow along and gain more insight into how network policies can be used in Kubernetes.
